IC-EDGE SIP-Client Extensions
Zenitel generates a ‘License Activation Code’ (LAC) which can be regarded as the actual article. In order for Zenitel to be able to generate a License Key, the License Activation Code must be registered at Zenitel together with the MAC-address of the IC-EDGE Controller for which the license is intended. Registration can be done by reporting the MAC-address and LAC in an e-mail to licensing@zenitel.com. More than one LAC can be listed on the registration form. All listed License Activation Codes together with the MAC-address will be used to generate a single License Key which will enable all licensed functions. The License Key will be shipped to the customer’s e-mail address. As the License key is rather complex, it should be inserted in the set-up program using the copy/paste function.
In case of service replacement of a IC-EDGE Controller, all licenses will remain available for a short period of time. A new lasting license key must be obtained for the new Controller during this period.
Additional licenses can be purchased at any time. Any new license will be added to already purchased licenses for the same hardware. A new license key will be issued to replace the existing license key; this will cover all the new and old legal licenses.
| Order number | |||
|---|---|---|---|
| 1009661201 | 1 x IC-EDGE-SIP-Client Extensions | ||
| 1009661206 | 6 x IC-EDGE-SIP-Client Extensions |
| General | |||
|---|---|---|---|
| Field of use | Expanding a IC-EDGE installation with 3rd party IP phones, IP DECT, PC and mobile clients | ||
| SIP | RFC 3261 (SIP base standard) RFC 3215 (SIP REFER) RFC 2976 (SIP INFO ) | ||
| SDP | RFC 4566 | ||
| DTMF | RFC 2833 RFC 2976 | ||
| RTP | RTP RFC 3550 | ||
| VoIP codec | G.711 (A & u law), G.722 (HD voice) |
