VS Recorder
Features
- AlphaCom Call Recording
- Audio and video stream recording
The VS Recorder software is a fully-featured IP based audio recorder with additional support for video recording. The software is flexible in its configuration and only required features need to be licensed.
AlphaCom Call Recording
The solution is able to record calls from all types of terminals connected to AlphaCom: analog and IP intercoms, analog and IP phones. Calls, conferences and group calls can all be recorded.
Stream Recording
The Recorder is in addition an NAVR – Network Audio/Video Recorder. For video, the NAVR is a fully featured NVR, but it is intended mainly as a video reorder for the video from AlphaCom video stations. Via the playback client it is possible to view live and recorded video.
AlphaCom intercom stations can be put in a permanent audio streaming mode. The Network Audio Recorder part of the software can record these audio streams for later review.
| Processing power * |
The required processing power depends on the overall system configuration. For calculating the required nr of processor cores and frequency the following can be taken as a guideline: |
||
|---|---|---|---|
| Operating System | Windows 7 or later, Windows Server 2008 or later | ||
| Specifications | |||
| Video – 150 MHz per stream | |||
| Audio – 75 MHz per stream | |||
| Memory | The minimum amount of available memory must be 4GByte | ||
| Maximum nr of AlphaCom recording modules | 10 | ||
| Maximum nr of simultaneously recorded AlphaCom calls | 64 | ||
| Maximum nr of simultaneously recorded audio/video streams | 64 |
| Order Numbers | |||
|---|---|---|---|
| 1190110100 | Vingtor-Stentofon Recorder – Base Module | ||
| 1190110110 | Vingtor-Stentofon Recorder – Playback/Configuration Client | ||
| 1190110120 | Vingtor-Stentofon Recorder – AlphaCom Recording Module | ||
| 1190110121 | Vingtor-Stentofon Recorder – AlphaCom Recording Module, AddOn | ||
| 1190110131 | Vingtor-Stentofon Recorder – Stream Recording Module, 1 stream | ||
| 1190110138 | Vingtor-Stentofon Recorder – Stream Recording Module, 8 streams | ||
| 1190110150 | Vingtor-Stentofon Recorder – Enterprise Management Server ** | ||
| 1190110160 | Vingtor-Stentofon Recorder – API | ||
| 1190110180 | Vingtor-Stentofon Recorder – Secure Audio Export |
